GDW220P
Protect operations from costly outages with the Pramac GDW220P. Rated at 200 kVA prime and 218.2 kVA standby, it is designed for commercial standby, industrial backup and site power. The set can be matched to the real load, motor-starting demands and operating environment rather than selected on nameplate size alone. The Perkins 1106A-70TAG4 engine and Mecc Alte ECO38 2S4 C alternator form a well-matched mechanical and electrical package for long-term standby or prime-power service. Integrate it with automatic transfer switching, remote monitoring, distribution and site fuel systems to create a complete power solution. Order the standard package or specify a custom build with a stainless-steel canopy, hot-dip galvanised skid base, super-silent enclosure, synchronising controls or an open generator set. CPS supports the full project—from load review and generator selection through to switchboards, fuel transfer, compliance testing and ongoing maintenance.
Download Specification Sheet→- 400/230 V, 50 Hz, three-phase output at 0.8 power factor
- 218.2 kVA / 174.6 kW ESP and 200 kVA / 160 kW PRP rating
- Perkins 1106A-70TAG4 1500 rpm water-cooled diesel engine
- Mecc Alte ECO38 2S4 C alternator, IP23, Class H insulation
- 75% PRP fuel consumption: 35.54 L/hr
- Fuel tank/runtime options: 8PFT (350 L) 9.85 h; | MFT-XS (500 L) 14.07 h; | MFT-S (600 L) 16.88 h; | MFT-M (1100 L) 30.95 h; | MFT-L (2200 L) 61.9 h
- Noise pressure: 68 dB(A) canopy @ 7 m
Industry-leading components, fully supported in Australia
Pramac
Pramac is a leading global manufacturer of stationary and mobile power generation equipment, founded in Casole d'Elsa, Tuscany in 1966. Now part of the Generac group, Pramac engineers diesel, petrol and battery energy storage solutions trusted by rental houses, mining sites and emergency services in over 150 countries.
Deep Sea Electronics
Deep Sea Electronics (DSE) has been designing intelligent generator and battery management controllers from Hunmanby, UK since 1975. Their controllers — including the iconic DSE 4520, 6020 and 7320 series — set the global standard for AMF / ATS automation, remote monitoring and over-current protection.
Perkins — Engine
Perkins is a British diesel engine manufacturer (part of Caterpillar Inc. since 1998), with engines in production since 1932 and over 22 million units built. Perkins powers the bulk of industrial-class Pramac generators — the 1100, 1300, 1700, 2200, 2500, and 4000 Series engines have a global service network and a reputation for reliability under continuous and prime-power duty cycles.
Mecc Alte — Alternator
Mecc Alte is the world's largest independent alternator manufacturer, headquartered in Vicenza, Italy since 1947. Their brushless synchronous alternators are renowned for exceptional voltage regulation, high efficiency and long service life — the engineering backbone of countless premium gensets.
- Model
- GDW220P/FNE
- Prime Power RPR
- TBC — refer to datasheet
- Emergency Stand-By Power ESP
- TBC — refer to datasheet
- Continuous power
- 176.0 kW
- Voltage
- 400/230 V
- Phase
- Three-phase
- Frequency
- 50 Hz
- Power factor
- 0.8
- Fuel
- Diesel
- Fuel Tank Size
- 1000 L
- Run time @ 75% Load
- TBC — refer to datasheet
- Engine
- Perkins 1106A-70TAG4
- Emission Level
- TBC — refer to datasheet
- Alternator
- Mecc Alte ECO38 2S4 C
- Canopy
- Sound-attenuated, traffic white RAL9016
- Noise @ 7 m
- 68 dB(A) canopy @ 7 m
- Dimensions/weight
- Canopy: 3700 x 1200 x 2052 mm, 2320 kg
- Product type
- stationary diesel generator set
- Standby / ESP output
- 218.2 kVA / 174.6 kW
- Prime / PRP output
- 200 kVA / 160 kW
- Engine speed
- 1500 rpm
- Engine cooling
- Water
- Engine cylinders/displacement
- 6 in line; | 7010 cm³
- Aspiration
- Turbocharged
- Governor
- Electronic
- Gross engine power
- 202 kWm ESP; | 183.6 kWm PRP
- Alternator rating
- 220 kVA standby @ 27°C; | 200 kVA continuous @ 40°C
- Alternator efficiency
- 92.7% @ 100% load
- Alternator voltage tolerance
- 1%
- IP protection
- IP23
- Cooling/airflow
- 267 m³/min
- Exhaust gas flow/temp PRP
- 34.9 m³/min; | 550 °C
- Fuel consumption @75% PRP
- 35.54 L/hr
- Fuel consumption @100% PRP
- 46.23 L/hr
- Fuel tank options
- 8PFT 350 L; | MFT-XS 500 L; | MFT-S 600 L; | MFT-M 1100 L; | MFT-L 2200 L
- Runtime @75% PRP
- 8PFT (350 L) 9.85 h; | MFT-XS (500 L) 14.07 h; | MFT-S (600 L) 16.88 h; | MFT-M (1100 L) 30.95 h; | MFT-L (2200 L) 61.9 h
- Electrical
- 12 V battery; | max current 318 A; | nominal current 289 A; | circuit breaker 300 A
- Emissions level
- Non Emission Certified
- Application
- commercial standby, industrial backup and site power
- Item number
- BT201TPA00A
